Stahlwille - 51040007

Features

Our torque tools, transducers and test equipment are delivered with a factory calibration certificate in accordance with DIN EN ISO 6789-2 and based on DKD-R 10-8 for traceability of the measuring equipment.

Properties

• indicating type
• the measuring element is a torsional leaf spring
• clockwise tightening (with trailing pointer) and anticlockwise tightening
• with 1/4" internal hex drive (F 6.3 DIN 3126)
• comparative scale in in·lb and cursor
• inserts and adaptors with external hex E 6.3 (1/4")
• DIN 3126/ISO 1173 are securely held and firmly controlled in the mounting shaft
• to attach 1/4" sockets, please order adaptor No 3115
• certificate in accordance with DIN EN ISO 6789-2:2017
• display deviation value ± 4%
