Klein Tools CL700 Electrical Tester is an automatically ranging true root mean squared (TRMS) digital clamp meter that measures AC current via the clamp, and measures AC/DC voltage, resistance, continuity, frequency, capacitance, and tests diodes via test-leads, and temperature via a thermocouple probe. It also features a Low Impedance (LoZ) mode for identifying and eliminating ghost or stray voltages. Klein Tools Test and Measurement product line was exclusively designed from the ground up by electricians for electricians. Years of field research, combined with extensive input from electricians across America, inspired the development of meters loaded with innovative, time-saving features.

  • Clamp Meter with automatically ranging true mean squared (TRMS) technology for increased accuracy
  • Electronic Tester's clamp measures AC current and its thermocouple probe measures temperature
  • Test leads measure AC/DC voltage, resistance, continuity, frequency and capacitance and tests diodes
  • Low Impedance (LoZ) mode for identifying and eliminating ghost or stray voltages
  • CAT IV 600V, CAT III 1000V, Class 2, Double insulation safety rating
  • Built to withstand a 6.6-Foot (2 m) drop
  • Low battery indicator and easily accessible battery compartment
  • Includes a carrying pouch, test leads, thermocouple with adapter and batteries
  • Meets requirements for use in basic and controlled electromagnetic environments like residential, office and light-industrial locations
  • Operating Temperature: 32-degrees F to 104-degrees F (0-degrees C to 40-degrees C)
  • Operating altitude to 6562-Foot (2000 m)

Additional Information

Application:Measures AC Current
Special Features:Features Low Battery Indicator
Batteries:2 x AAA
Jaw Size:1.38"" (3.5 cm)
Drop Protection:6.6" (2 m)
Display:6000 Count LCD
Functions:Clamp measures AC current and thermocouple probe measures temperature. Test leads measure AC/DC voltage, resistance, continuity, frequency and capacitance and tests diodes
Voltage:1000V AC; 1000V DC
Frequency:1Hz - 500 KHz
Current:600A
Capacitance:6000µF
Ohms (Resistance):60MO
Temperature Range:-14° - 1000°F (-26° - 538°C)
Ingress Protection:IP40
Standard:CAT IV 600V; CE Certified
Included:Carrying Case, Test Leads, Thermocouple with Adapter, and Batteries
Overall Length:9.09"" (23.1 cm)
Overall Height:1.55"" (3.9 cm)
Overall Width:3.81"" (9.7 cm)
Weight:11.8 oz (335 g)
